Notes from Efficiently Serving LLMs

Course: Efficiently Serving LLMs Platform: DeepLearning.io

Deep Learning

Text Generation

Input text is tokenized into numbers (called tensors).
The tensor is fed to a model that gives the top-k predictions for the next token.
Take the top prediction and append it to the input, either until the maximum number of tokens are created or a stop token is reached.
For a sequence without padding, the attention mask can contain 1 for every token.
During attention, the model computes Key (K) and Value (V) tensors. These can be stored in a KV cache for each transformer layer and reused during subsequent token generation.
Cache the K-V matrix and pass that to the model, so that only the incremental value can be computed instead of starting computation from the first token while calculating attention.

The K-V cache contains the values that have already been computed and can be reused for subsequent tokens.

                    Attention computation
                         +-----------+
                         |     A     |
                         +-----+-----+
                               |
              +----------------+----------------+
              |                                 |
              v                                 v
        New input token                    Cached K-V
              |                         +-----------------+
              v                         | K1 K2 K3 ...   |
        +-----------+                   | V1 V2 V3 ...   |
        |  Q, K, V  |                   +-----------------+
        | for token |                          |
        +-----------+                          |
              |                                 |
              +----------------+----------------+
                               |
                               v
                         Attention uses:
                         Q(new) with
                         K1...Kn + K(new)
                         V1...Vn + V(new)
                               |
                               v
                       Next-token logits
                               |
                               v
                         Next token
                               |
                               |
                               +------------------+
                                                  |
                           K(new), V(new)         |
                                                  v
                 +---------------------+      +-------+
                 |     Updated K-V     | <----| Append|
                 |                     |      +-------+
                 | K1 K2 K3 ... Kn+1  |
                 | V1 V2 V3 ... Vn+1  |
                 +---------------------+
                              |
                              +----> cache for next step

Prefill and Decode

Prefill phase — process the entire input prompt and build the initial KV cache. The output is used to generate the first token. (slowest)

Decode phase — generate subsequent tokens one at a time. (can use K-V cache)

Batching

Batching: Parallelly process N sequences of tokens.

If the number of tokens in each sequence is different, use padding tokens on the left and set the attention mask value to `0`, so that the model does not pay attention to it.

For example:
```
[The] [cat] [sat]
[The] [home] [on] [the]
[A]   [boy]
```
After padding:
```
[PAD] [PAD] [The] [cat] [sat]
[PAD] [The] [home] [on] [the]
[PAD] [PAD] [PAD] [A] [boy]
```
The model can then generate the next token for each sequence.
Here, in the output from the model, keep all the elements in the batch.

Next, instead of taking `argmax` of the entire output, take the max of each row to choose the next token for that sequence.
If you do this efficiently for every loop to see if a sequence is ready to be removed from the batch or a new one can be added, that's continuous batching. This can improve throughput.
